CS11

Compact Media Isolated Pressure Sensor

Features

  • ≤ ±0.25% BFSL accuracy
  • Pressures from 2 PSI up to 2,000 PSI
  • Compact design
  • Flush diaphragm available

Great For…

  • Pressure control panels
  • Low pressure monitoring
  • General industrial equipment
  • Pressure measurement in confined spaces
Datasheet

**Disclaimer: Unless otherwise agreed in writing, Core Sensors products are not authorized for use in applications including medical devices, life support systems, in-flight aerospace, nuclear or any other application where the product failure could result in personal injury or death.

About the CS11

The CS11 Compact Media Isolated Pressure Sensor features a silicone sensing element isolated by a fluid filled cavity. Configurations are available with a millivolt output signal and 316L SS wetted material for compatibility in a variety of medias. With available pressure ranges from 0-2 up to 2,000 PSI, the CS11 is an economical choice in applications with minimal installation space.

Approvals/Certifications

Small Profile – Excellent Performance

The CS11 Compact Media Isolated Pressure Sensor is the ideal sensor for applications requiring a small profile with reliable, repeatable performance. Threadless configurations with an O-ring seal are available for easy installation into pressure manifolds. Need a threaded connection? No problem! The CS11 can also be configured with a threaded process connection such as 1/4” or 1/8” Male NPT.

The CS11 not only offers a small profile but also high performance. Pressure is transferred from the 316L SS diaphragm to the sensing element via a fluid filled cavity. This fluid filled design results in a highly stable and fast response pressure measurement over a wide operating temperature range.

Don’t see the configuration you require? Contact Core Sensor today and let us know your requirements! The CS11 features a configurable design, allowing broad customization possibilities.

Specifications

Performance

Accuracy @ 25°C*
≤ ± 0.25% BFSL
≤ ± 0.5% BFSL (2 PSI)

Stability (1 Year)
≤ ± 0.25% of FS

Pressure Cycles
10 million

Overpressure
2X minimum

Burst Pressure
5X or 4,000 PSI, whichever is less

* Accuracy includes non-linearity, hysteresis and non-repeatability

Thermal

Operating Temperature
-40 to +120°C

Compensated Temperature
0 to +70°C

Storage Temperature
-40 to +125°C

TC Zero
≤ ± 1.5% of FS

TC Span
≤ ± 1.5% of FS

Environmental

EMI/RFI Protection
No

Vibration
10g, 20 to 2000Hz

Shock
100g, 11msec, 1/2 sine

* IP Rating is dependent on electrical termination selected. Contact factory for more information.
* IP Rating applies when electrical connector is attached with the appropriate ingress protection.

Electrical (Millivolt)

Outputs
10mV/V

Excitation
5VDC typical
10VDC typical

Current Consumption
<5mA

Input Impedance
5000 Ohms, typical

Output Impedance
5000 Ohms, typical

Zero Offset (of FS)
≤ ± 2%

Span Tolerance (of FS)
≤ ± 2%

Specifications are subject to change without notice

Model Number Configuration

Not all configurations are available. Our sales team can recommend the closest available configuration based on your requirements.
Contact Core Sensors for configurations not shown.

– Ordering Example: CS11-2A00100PG9U000 (1/4″ Male NPT, 316L SS, 0-100 PSI gauge, 10mV/V, 4-Pin Molex)

Note: Mobile users can use the zoom feature to view the model number configuration matrix clearly.

Dimensions

Note that dimensions are for reference only. Please contact us if you do not see a dimension listed.

Note: Mobile users can use the zoom feature to view the dimensions clearly.
